Tablet ESD protection solution

In the ESD protection design of flat plates, it is required that the protection components have a compact size to accommodate the limited space inside the flat plate. Meanwhile, these components need to have a medium rated current to ensure that they do not fail due to excessive current under normal usage conditions. In addition, the low-loss feature is of vital importance as it can reduce energy dissipation and enhance the overall energy efficiency of the tablet. The MWSD-FE series of wound ferrite inductors, with their low DC and AC resistance and saturation current that can meet application requirements, have become an ideal choice for ESD protection design of flat plates. They not only achieve efficient electrostatic protection but also ensure the battery life of the flat plates.

Design of tablet protection scheme

CVB1005E601T

ESD0524UA

ESD5D090TA

ESD0524UA
