HDMI port design scheme

In the EMC design of HDMI ports, we focus on the exquisite design and efficient performance of inductors. The selected inductor should have a compact form factor to meet the compact layout requirements of the HDMI port. Meanwhile, it should have a medium rated current to ensure smooth transmission of high-definition video and audio data. Low-loss characteristics are the key to achieving high conversion efficiency, which helps enhance the overall performance of the system and extend the battery life of the equipment.

HDMI EMC Port design scheme

CMF2012WD900MQT

ESD0524UA

ESD0524UA

ESD5D150TA
